Position：| Items | Specification |
| Diagonal Size | 10.1inch Touch Module |
| Product Number | DR-T-G101-ILI-A01 |
| LCD | G101EAN01.0 |
| Resolution | 800(RGB)×1280 |
| Brightness | 350 |
| Active Area(mm) | 135.36(W)×216.576(H) mm |
| Bezel Opening(mm) | 143.5(W)×220(H)×10.2(D) mm |
| Response Time | 30 (Typ.)(Tr+Td) ms |
| Viewing Angle | 85/85/85/85 |
| Pixel Format | RGB Vertical Stripe |
| Display Mode | AHVA, Normally Black, Transmissive |
| Display Colors | 16.7M , 72% NTSC |
| Contrast Ratio | 1000:1 |
| Surface | Antiglare, Antireflection |
| Power Supply | 3.3V |
| Signal Interface | MIPI (4 data lanes) , 39 pins Connector |
| Operating Temp | 0 ~ 50 °C |
| Storage Temp | -20 ~ 60 °C |
| Light Transmittance | >87% |
| Cover Glass | 2mm Tempered Glass |
| Surface Hardness | ≥6H |
| Touch Interface | USB |
| Touch Structure | G+G |
| Touch Controller | ILITEK |
| Operating environment | Industry |
| Warranty period | One Year |
