Position：Customizable backlight brightness：700/1000nits，Suitable for outdoor, semi-outdoor and indoor
24-hour consultation hotline
13816749069
| Items | Specification |
| Diagonal Size | 12.1" |
| Resolution | 1024*768 |
| Brightness | 1000nits |
| Active Area(mm) | 245.76(W)×184.32(H) mm |
| Bezel Opening(mm) | 260.5(W)×204(H)×9.2(D) mm |
| Response Time | 30 (Typ.)(Tr+Td) ms |
| Viewing Angle | 86/86/86/86 |
| Pixel Format | RGB Vertical Stripe |
| Display Mode | ADS, Normally Black, Transmissive |
| Display Colors | 16.7M , 72% NTSC |
| Contrast Ratio | 1200:1 |
| Surface | Antiglare, Hard coating (3H) |
| Power Supply | 3.3V |
| Signal Interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Operating Temp | -20 ~ 70 °C |
| Storage Temp | -30 ~ 80 °C |
| Product certification | RoHS |
| Backlit life | 50000 hr |
