Position：Customizable backlight brightness：700/1000/1500/2000nits，Suitable for outdoor, semi-outdoor and indoor
24-hour consultation hotline
13816749069
| Items | Specification |
| Diagonal Size | 15.0" |
| Resolution | 1024*768 |
| Brightness | 1000nits |
| Active Area(mm) | 304.128(W)×228.096(H) mm |
| Bezel Opening(mm) | 306.5(W)×230.1(H) mm |
| Response Time | 30 |
| Viewing Angle | 89/89/89/89 |
| Pixel Format | RGB Vertical Stripe |
| Display Mode | ADS, Normally Black, Transmissive |
| Display Colors | 16.7M 72% NTSC |
| Contrast Ratio | 1000:1 |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Power Supply | 3.3V |
| Signal Interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Operating Temp | -20 ~ 70 °C |
| Storage Temp | -20 ~ 70 °C |
| Product certification | RoHS |
| Backlit life | 50000 hr |
