Position：Customizable backlight brightness：700/1000/1500/2000nits，Suitable for outdoor, semi-outdoor and indoor
24-hour consultation hotline
13816749069
| Items | Specification |
| Diagonal Size | 17.0" |
| Resolution | 1280*1024 |
| Brightness | 1000nits |
| Active Area(mm) | 337.92(W)×270.336(H) mm |
| Bezel Opening(mm) | 358.5(W)×296.5(H) mm |
| Response Time | 15/5 (Typ.)(Tr/Td) ms |
| Viewing Angle | 80/80/70/70 |
| Pixel Format | RGB Vertical Stripe |
| Display Mode | TN, Normally White, Transmissive |
| Display Colors | 16.7M 72% NTSC |
| Contrast Ratio | 700:01:00 |
| Surface | Antiglare, Hard coating (3H) |
| Power Supply | 5.0V |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Operating Temp | -30 ~ 85 °C |
| Storage Temp | -30 ~ 85 °C |
| Product certification | RoHS |
| Backlit life | 50000 hr |
