Position：Customizable backlight brightness：700/1000/1500/2000nits，Suitable for outdoor, semi-outdoor and indoor
24-hour consultation hotline
13816749069
| Items | Specification |
| Diagonal Size | 19.0" |
| Resolution | 1280*1024 |
| Brightness | 1000nits |
| Active Area(mm) | 374.784(W)×299.827(H) mm |
| Bezel Opening(mm) | 396(W)×324(H)×10.4(D) mm |
| Response Time | 14 (Typ.)(G to G) ms |
| Viewing Angle | 89/89/89/89 |
| Pixel Format | RGB Vertical Stripe |
| Display Mode | HADS, Normally Black, Transmissive |
| Display Colors | 16.7M 72% NTSC |
| Contrast Ratio | 1000:1 |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Power Supply | 5.0V |
| Signal Interface | LVDS (2 ch, 8-bit) , Connector 30 pins |
| Operating Temp | 0 ~ 50 °C |
| Storage Temp | -20 ~ 60 °C |
| Product certification | RoHS |
| Backlit life | 50000 hr |
